X Series Coil

Robust Design

Eliminates stray currents in tanks. Excellent chemical compatibility and rugged design for your heating orcooling application. All wetted parts of fuoropolymer (FEP, PFA or PTFE) construction with a heavy duty CPVcmounting bracket, Standard coils are FEP and rated up to 30 pSl steam service. PFA coils are available forsteam service up to 60 psl. 10 psl minimum steam pressure required for operation. Heavy wall tubingimproves circulations and reduces pressure drop. Heavy duty CpVC mounting bracket and 1/8-inch thickperforated guard helps protect the coil from damage. integral inlet/outlet connections reduce potential forleaks,10 PSl minimum steam pressure required for operation.

Vacuum breakers recommended for fluoropolymer heat coil steam heating installations.
